Assembly instructions for V- and U-shaped fitting room

Lay out all parts so you have a clear overview before assembly.

Included:
1 pc. Curtain rod (L- or U-shaped)
2 pcs. Wall brackets
1 pc. Wire with wire clips
2 pcs. Curtain panels (H: 190 cm)
20 pcs. Hooks

Installing the curtain rod

Attach the first wall bracket to the wall at an appropriate height and distance.
Adjust the height according to the length of the panel.
Determine the distance based on the desired placement in the room.

Mount the curtain rod onto the wall bracket.
Secure the last wall bracket to the curtain rod, then install it on the wall.

Installing the wire suspension
For L-shaped fitting rooms, mount the wire suspension at the corner of the curtain rod.

For U-shaped fitting rooms, mount the wire suspension in the center of the section of the curtain rod that runs parallel to the wall. The wire suspension is mounted in a glider at the top of the curtain rod.

Note: U-shaped fitting rooms include 2 panels in different widths.
Be sure to install them to achieve the best visual and practical result.
